Product Details
Place of Origin: China
Brand Name: Solarsonc
Certification: CE/TUV/UN38.3
Model Number: CESS-GXY200
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Delivery Time: 30 working days
Supply Ability: 10 sets per month
Name: |
100KW Commercial And Industrial Energy Storage |
Rated Battery Storage Capacity: |
215KWH |
Rated Power: |
100KW |
Charge-Discharge Ratio: |
0.5C/25℃±2℃DC 500-900V |
Rated Input Voltage: |
768 |
Battery Type: |
LiFePo4 Battery (LFP) |
Battery Capacity: |
280AH |
Rated AC Power: |
100KW |
Rated AC Current: |
150A |
Rated AC Voltage: |
380V |
Harmonic Distortion: |
<3% |
Protection Level: |
IP55 |
Communication: |
TCP/IP |
Operating Temperature: |
-20~55℃ |
Operating Humidity: |
0-95% |
Cooling Method: |
Air Conditioning Cooled |
Altitude: |
<3000m |
Dimension: |
1750*1215*2340mm |
Cycle Life: |
≥6000 （25℃，0.5C，90%DOD，70%EOL） |
Weight: |
3Ton |
Application: |
Commercial/Industrial |
Installation: |
Indoor/Outdoor |
Monitoring Software: |
Web-based |
Safety Features: |
Overcharge Protection, Short Circuit Protection, Thermal Protection |
Shippment: |
Please Contact Us For Details |
Name: |
100KW Commercial And Industrial Energy Storage |
Rated Battery Storage Capacity: |
215KWH |
Rated Power: |
100KW |
Charge-Discharge Ratio: |
0.5C/25℃±2℃DC 500-900V |
Rated Input Voltage: |
768 |
Battery Type: |
LiFePo4 Battery (LFP) |
Battery Capacity: |
280AH |
Rated AC Power: |
100KW |
Rated AC Current: |
150A |
Rated AC Voltage: |
380V |
Harmonic Distortion: |
<3% |
Protection Level: |
IP55 |
Communication: |
TCP/IP |
Operating Temperature: |
-20~55℃ |
Operating Humidity: |
0-95% |
Cooling Method: |
Air Conditioning Cooled |
Altitude: |
<3000m |
Dimension: |
1750*1215*2340mm |
Cycle Life: |
≥6000 （25℃，0.5C，90%DOD，70%EOL） |
Weight: |
3Ton |
Application: |
Commercial/Industrial |
Installation: |
Indoor/Outdoor |
Monitoring Software: |
Web-based |
Safety Features: |
Overcharge Protection, Short Circuit Protection, Thermal Protection |
Shippment: |
Please Contact Us For Details |
100KW/200KWH commercial and industrial energy storage
| System Data | |
| Dimensions(W*D*H) | 1750*1215*2340 |
| Weight | 3 tons |
| Operating Temperature | -20℃~55℃ |
| Protection Class | IP54 |
| Altitude | ≤3000m |
| Humidity | 0~95% |
| System energy efficiency | ≥90% |
| Fire Extinguishing | Perfluoro |
| Cooling Type | Aie Cooling |
| Anti-Corrosion | C3 |
| Certificates | CE/TUV/UN38.3 |
| Communication | TCP/IP |
| Noise Level | ≤75dB |
| Battery Data | |
| Battery Type | LFP 280Ah |
| Rated Voltage | 768V |
| DC Scale | 600~864V |
| Rated Capacity | 215KWh |
| Rated Power | 100KW |
| Rated Current | 140A |
| Cycle Life | ≥6000 (@25℃,0.5C/0.5C,90%DOD,70%EOL) |
| Battery Efficiency | 95% |
| AC Data | |
| AC mode | 3P/PE |
| AC Power | 100KW |
| AC Current | 150A |
| Power Factor | -1~+1 |
| Rated Voltage | 380V |
| Harmonic Distortion | ≤3% |
| Rated grid frequency | 50/60Hz |
Brackets
Aluminium Alloy, Stainless Steel, Hot-dip Galvanized Steel,Ground Screw Mounting, Adjustable Brackets, Solar Tracker
Installation Site
Color Steel Tile/Tin Pitched Roof, Flat Roof, Cement/Soil Ground, Carport, etc
Installation Tools
Wire Cable Cutter & Stripper, Multi-Meter, Insulating gloves/covering etc
1. Are you a manufacturer or trading company?
A: We are a manufacturer .
2. How much life span of the battery?
A: Our batteries are built with grade A lifepo4 cell, cycle life up to 8000+ at 80% DoD
3. How long is the warranty?
A: we offer 10 years truly warranty to provide after-sale service and technology support. Including resend new battery or
replacement BMS.
4. What brand inverter are your batteries compatible?
A: Our BMS supports the following communications Canbus/RS485/RS232 and can compatible with most of famous inverters
5. What is the delivery time? What is your standard packing?
A: Usually delivery in 25-30days, but could be changed according to the quantity or other things.
6. Do you support customization?
A: YES, LOGO/sticker/OEM/ODM welcomed .
7. What are your terms of payment?
A: The payment term will be 30%T/T for deposit and the balance before shipment .
8. Do you have CE/ MSDS/ UN38.3 / certification for safe transport of goods?
A: YES, We do!
