Product Details
Payment & Shipping Terms
Name: |
LFP Lithium Ion Battery Module 28Ah 102.4 V 2.867kWh |
Chemistry System: |
LFP |
Cell Package Type: |
Cylindrical Cell (stainless Steel Shell )32135FS |
Module Dimensions: |
L510×W235×H160 Mm |
Module Nominal Capacity: |
56Ah |
Module Nominal Voltage: |
51.2 V |
Module Nominal Energy: |
2.867kWh |
Series & Parallel Scheme: |
4P16S |
Application: |
ESS |
Name: |
LFP Lithium Ion Battery Module 28Ah 102.4 V 2.867kWh |
Chemistry System: |
LFP |
Cell Package Type: |
Cylindrical Cell (stainless Steel Shell )32135FS |
Module Dimensions: |
L510×W235×H160 Mm |
Module Nominal Capacity: |
56Ah |
Module Nominal Voltage: |
51.2 V |
Module Nominal Energy: |
2.867kWh |
Series & Parallel Scheme: |
4P16S |
Application: |
ESS |
lithium ion battery module
battery module testing and PACK laboratories. Customized solutions are provided to customers, with module, and PACK designs. 24 patents and software copyrights, it could guarantee the safe operation of enterprises and provide strong technical support for our products.
The battery module is equipped with the acquisition module BMU of BMS, which is used to acquire parameters such as voltage and
temperature of the module
Laser welding to ensure penetration depth and width.
Energy efficiency ≥ 95% @ 0.5P normal temperature.The annual module fault tolerance rate is 0.5 ‰.
Specification
| Item | (Product Specification) |
| Chemistry System | LFP |
| Cell Package Type | Cylindrical cell (stainless steel shell )32135FS |
| Module Dimensions | L510×W235×H160 mm |
| Module Nominal Capacity | 56Ah |
| Module Nominal Voltage | 51.2 V |
| Module Nominal Energy | 2.867kWh |
| Series & Parallel Scheme | 4P16S |
| Application | ESS |
